ISO 15156-2:2020 Standard
ISO 15156-2:2020 sets the rules for selecting and qualifying carbon and low-alloy steels against sulfide stress cracking and related cracking in H₂S service. The full title is Petroleum and natural gas industries — Materials for use in H₂S-containing environments in oil and gas production — Part 2: Cracking-resistant carbon and low-alloy steels, and the use of cast irons.
Part 2 holds what Part 1 leaves out for ferrous materials: the four SSC regions of environmental severity, the hardness ceilings, the weld acceptance criteria, the qualified steel grades and the laboratory test matrix. Where a material sits on the H₂S partial pressure and pH map decides which annex you may select from.
ISO 15156-2 is published jointly as NACE MR0175/ISO 15156 Part 2. This guide covers the scope, the two selection options, the four SSC regions, parent metal and weld hardness limits, qualified tubular and casing grades, cold deformation rules, HIC and SWC evaluation, the Annex B test matrix, the point where carbon steel runs out of road, documentation duties, applications and FAQs.
ISO 15156-2:2020 Free DownloadWhat Is ISO 15156-2:2020?
ISO 15156-2:2020 gives requirements and recommendations for selecting and qualifying carbon and low-alloy steels, and for the use of cast irons, in equipment exposed to H₂S-containing environments in oil and gas production. It applies where failure would risk the health and safety of the public and personnel, or the environment.
This fourth edition was published in November 2020 and replaces ISO 15156-2:2015. Annex C (informative) was modified in 2020 to add alternative parameters and an expanded explanation of chemical activity and fugacity. Partial pressure remains acceptable for systems with a gas phase (C.1). Gas-free liquids use a bubble-point virtual partial pressure (C.2), and for high-pressure oil wells (typically above 350 bar) fugacity or activity calculations are recommended. Annex D provides the matching guidance on determining in situ pH.
Part 2 covers three cracking mechanisms for selection purposes — SSC, SOHIC and SZC — plus a separate evaluation route for HIC and SWC. Steels conforming with Annex A might not resist SOHIC, SZC, HIC or SWC without additional requirements, a caveat the standard states plainly in Annex A.1.
Where Part 2 Sits in the ISO 15156 Series
Three parts divide the work between method and material family. Reading Part 2 without Part 1 leaves you with limits and no way to establish the service conditions they apply to.
| Standard | Material Scope | What You Get From It |
| ISO 15156-1 | All metallic materials | Selection method, definitions, 7 cracking mechanisms, qualification routes, reporting duties |
| ISO 15156-2 | Carbon and low-alloy steels, cast irons | 4 SSC regions, hardness limits, weld criteria, Annex A steel lists, Annex B test matrix |
| ISO 15156-3 | CRAs and other alloys | Annex A tables of qualified stainless, duplex and nickel alloys with environmental envelopes |
The three parts share two test standards. NACE TM0177 covers laboratory SSC and SCC testing; NACE TM0284 covers HIC evaluation of pipeline and pressure vessel steels. NACE TM0316 is referenced for four-point bend assessment, a reference change introduced in the 2020 edition. The ISO 15156-1 standard page sets out the selection method, and the ISO 15156-3 standard page carries the CRA envelopes.
9 Factors Affecting Carbon Steel Behaviour in H₂S Environments
Clause 6 lists nine parameters whose complex interactions govern how carbon and low-alloy steels behave in sour environments. All nine must be considered when selecting material under this document; the standard does not treat any as optional.
- Material condition — chemical composition, manufacturing method, product form, strength, hardness and its local variations, cold work, heat-treatment condition, microstructure, microstructural uniformity, grain size and cleanliness
- H₂S partial pressure — or the equivalent concentration in the water phase
- Chloride ion concentration — in the water phase
- Acidity (pH) — of the water phase
- Presence of sulphur or other oxidants
- Exposure to non-production fluids — stimulation acids and their backflow sit here
- Exposure temperature
- Total tensile stress — applied plus residual
- Exposure time
Note what sits at the top of that list. The standard states that hardness control can be an acceptable means of obtaining SSC resistance (7.3.1).
2 Options for Selecting SSC-Resistant Steels
Part 2 gives two selection routes. Option 1 is a lookup against Annex A and needs no testing. Option 2 qualifies a steel for a specific application or a defined range of sour service, and it can override the Annex A limits for that material.
Option 1: Selection Using Annex A.2
If the H₂S partial pressure in the gas is 0.3 kPa (0.05 psi) or greater, SSC-resistant steels shall be selected using Annex A.2. Steels conforming with A.2 are qualified without further SSC testing, with stated exceptions. The majority of conforming steels are not individually listed; Tables A.2 to A.4 give examples rather than an exhaustive set.
Below 0.3 kPa (0.05 psi) the standard does not address selection in detail and normally no special precautions are required. Highly susceptible steels can still crack at that level, so the absence of a requirement is not a guarantee of immunity.
Option 2: Qualification for Specific Applications or Service Ranges
Option 2 lets the user qualify steels for specific sour-service applications or for ranges of sour service. The limits established by Option 2 qualification may replace any limits listed for that material in Annex A.2. Using it requires knowledge of both in situ pH and H₂S partial pressure, plus how each varies with time.
The commercial case is specific. Option 2 suits bulk purchases of OCTG and line pipe, where the saving from using a steel outside Annex A outweighs the qualification cost. It also supports fitness-for-purpose evaluation of existing equipment now facing conditions more severe than the original design assumed.
4 SSC Regions of Environmental Severity: Region 0, 1, 2 and 3
Figure 1 of the standard maps H₂S partial pressure against in situ pH and divides the result into four regions. The region you land in decides which part of Annex A you may select from, and severity rises as H₂S climbs and pH falls.
| Region | Position on the Map | Selection Source Permitted | Practical Reading |
| Region 0 | Below 0.3 kPa (0.05 psi) H₂S | No requirement; precautions optional | Mildly sour; susceptible steels can still crack |
| SSC Region 1 | Lowest severity above the 0.3 kPa threshold | A.2, A.3 or A.4 | Widest choice of steels |
| SSC Region 2 | Intermediate severity | A.2 or A.3 | A.4 steels no longer permitted |
| SSC Region 3 | Highest severity — high H₂S, low pH | A.2 only | Narrowest choice; strictest limits |
Two discontinuities appear in Figure 1, below 0.3 kPa (0.05 psi) and above 1 MPa (150 psi) H₂S partial pressure. They reflect measurement uncertainty at low partial pressure and uncertainty about steel performance outside those limits at both ends of the range.
When defining severity, the standard asks users to account for exposure to unbuffered, condensed aqueous phases of low pH during upset conditions or downtime. Acids used for well stimulation and the backflow of spent stimulation acid belong in the same assessment.
Region 0 Still Carries Risk
Four conditions deserve attention even in Region 0. Highly susceptible steels can crack. Physical and metallurgical properties still govern inherent resistance. Stress concentrations raise the risk. And above roughly 965 MPa (140 ksi) yield strength, very high-strength steels can suffer HSC in aqueous environments with no H₂S present at all.
What Regions 2 and 3 Mean for Steel Choice
At publication there were no listings of steels approved specifically for Region 2 (A.3) or Region 1 (A.4). Both annexes describe typical properties rather than naming grades. For Region 2, Cr-Mo low-alloy tubulars have proven acceptable at actual yield up to 760 MPa (110 ksi) and hardness no more than 27 HRC, with pipeline steels up to 450 MPa (65 ksi) SMYS and weld hardness not exceeding 280 HV.
Region 1 allows more. Cr-Mo tubulars have proven acceptable at actual yield up to 896 MPa (130 ksi) and hardness no more than 30 HRC, with pipeline steels up to 550 MPa (80 ksi) SMYS and weld hardness not exceeding 300 HV. Region 3 permits neither relaxation — A.2 is the only source.
Hardness Requirements for Parent Metal
Carbon and low-alloy steels are acceptable at 22 HRC maximum hardness provided they contain less than 1 % mass fraction nickel, are not free-machining steels, and are supplied in one of six permitted heat-treatment conditions. The 22 HRC limit comes from correlations of heat treatment, chemical composition, hardness and field failure experience built up across every revision of NACE MR0175.
| Material or Product | Maximum Hardness | Condition Required |
| Carbon and low-alloy steels (general) | 22 HRC | Hot-rolled (carbon only), annealed, normalized, normalized and tempered, normalized + austenitized + Q&T, or austenitized + Q&T |
| ASTM A105 forgings | 187 HBW | Per A.2.1.3 a) |
| ASTM A234 grades WPB and WPC fittings | 197 HBW | Per A.2.1.3 b) |
| Cr-Mo tubulars (UNS G41XX0), 690–760 MPa SMYS | 30 HRC | Q&T in tubular form; SSC testing of each batch required |
| Cr-Mo tubulars (UNS G41XX0), general | 26 HRC | Q&T in tubular form; SSC testing recommended |
| BOP rams, Cr-Mo Q&T | 26 HRC | Above 22 HRC requires careful composition and heat treatment control plus SSC testing |
| Cold-worked A53 Gr B / A106 Gr B / X-42 fittings | 190 HBW | Cold strain 15 % or less |
The standard allows a small tolerance on individual readings. An HRC reading above the permitted value may be accepted if the average of several readings taken in close proximity stays within the limit and no single reading exceeds it by more than 2 HRC. Equivalent rules apply to other hardness methods when specified.
Weld Hardness Acceptance Criteria
Welding changes the metallurgy, and the changed metallurgy drives susceptibility to SSC, SOHIC and SZC. Qualification of welding procedures for sour service must include hardness testing, and Table A.1 sets the ceilings.
| Test Method | Location | Maximum Hardness |
| Vickers HV 10 / HV 5 or Rockwell HR 15N | Weld root — base metal, HAZ and weld root metal | 250 HV or 70.6 HR 15N |
| Vickers HV 10 / HV 5 or Rockwell HR 15N | Base metal and HAZ for weld overlays | 250 HV or 70.6 HR 15N |
| Vickers HV 10 / HV 5 or Rockwell HR 15N | Weld cap — base metal, HAZ and unexposed weld cap metal | 275 HV or 73.0 HR 15N (conditional) |
| Rockwell HRC | Base metal and HAZ per Figure 5 | 22 HRC |
| Rockwell HRC | Base metal and HAZ for weld overlays | 22 HRC |
| Post-weld heat treated weldments | Maximum weld zone hardness | 250 HV or 22 HRC |
The 275 HV weld cap allowance is conditional, not automatic. All three conditions must be met: the equipment user agrees the alternative limit, parent material is over 9 mm thick, and the weld cap is not exposed directly to the sour environment. Otherwise the limit reverts to 250 HV or 70.6 HR 15N.
As-welded carbon, carbon-manganese and low-alloy steels meeting Table A.1 do not require post-weld heat treatment. Weldments failing those requirements must be PWHT after welding, with a minimum PWHT temperature of 621 °C (1,150 °F) for low-alloy steels.
HV 10 or HV 5 per ISO 6507-1, or Rockwell 15N per ISO 6508-1, are the normal methods. The HRC method is permitted for welding procedure qualification only where design stress does not exceed two-thirds of SMYS and the procedure includes PWHT; any other use needs the equipment user’s agreement. Vickers and 15N surveys give a more detailed picture and may detect small hard zones that an HRC survey misses.
Qualified Carbon Steel Grades Under Annex A
Annex A gives example lists rather than a closed set. Table A.2 covers tubular products, Table A.3 covers casing and tubing by temperature, and Table A.4 covers bolting. Pressure vessel steels classified P-No 1 Group 1 or 2 in ASME Section IX are acceptable.
Tubular Products (Table A.2)
Examples of tubular products that can conform with the general requirements of A.2.1.
| ISO Specification and Grades | Equivalent Designations |
| ISO 3183 grades L245 through L450 | API Specification 5L grades A, B and X-42 through X-65 |
| — | ASTM A53 |
| — | ASTM A106 grades A, B and C |
| — | ASTM A333 grades 1 and 6 |
| — | ASTM A524 grades 1 and 2 |
| — | ASTM A381 class 1, Y35 to Y65 |
Pipe seam welds shall conform with A.2.1. A qualified parent metal with an unqualified seam weld does not satisfy the standard, and the seam is where hardness excursions most often appear in welded line pipe.
Casing and Tubing by Minimum Service Temperature (Table A.3)
Higher-strength casing and tubing grades become acceptable only above a minimum service temperature. The temperatures are minimum allowable service temperatures with respect to SSC; low-temperature toughness is a separate assessment the equipment user must make.
| Minimum Service Temperature | Acceptable ISO 11960 / API 5CT Grades |
| All temperatures | H40, J55, K55, M65, L80 type 1, C90 type 1, T95 type 1, plus proprietary grades per A.2.2.3.3 |
| ≥ 65 °C (150 °F) | N80 type Q, R95, C110; proprietary Q&T grades up to 760 MPa (110 ksi) max yield; Cr-Mo casing per A.2.2.3.2 |
| ≥ 80 °C (175 °F) | N80, P110; proprietary Q&T grades up to 965 MPa (140 ksi) max yield |
| ≥ 107 °C (225 °F) | Q125 |
Q125 carries an extra restriction. Types 1 and 2 are based on Q&T Cr-Mo chemistry to 1,036 MPa (150 ksi) maximum yield, and C-Mn steels are not acceptable in that grade. R95 and the former C95 designation are deemed equivalent.
Bolting and Fasteners (Table A.4)
Bolting exposed directly to a sour environment, buried, insulated, fitted with flange protectors or otherwise denied atmospheric or open seawater exposure must conform to A.2.1. Acceptable materials are ASTM A193 grade B7M and ASTM A320 grade L7M for bolts, with ASTM A194 grades 2HM and 7M for nuts. Using SSC-resistant bolting can require lowering equipment pressure ratings.
Cold Deformation and Stress Relief Rules
Carbon and low-alloy steels shall be thermally stress-relieved following any cold deforming that produces permanent outer fibre deformation greater than 5 %. The minimum stress-relief temperature is 593 °C (1,100 °F) and final maximum hardness is 22 HRC, except for A234 WPB and WPC fittings at 197 HBW.
Three carve-outs apply. Cold work from pressure testing to an applicable code does not trigger the rule. Cold-rotary straightened pipe is acceptable only where the applicable ISO or API product standard permits it. Cold-worked line pipe fittings in A53 Gr B, A106 Gr B, API 5L X-42, ISO 3183 L290 or lower grades are acceptable at 15 % strain or less provided strained-area hardness stays at or below 190 HBW.
For tubulars, cold-straightening at or below 510 °C (950 °F) requires stress relief at a minimum of 482 °C (900 °F). Cold-formed regions exceeding 5 % outer fibre deformation need 593 °C (1,100 °F). Cold-formed connections on tubulars above 22 HRC need the same 593 °C treatment.
Surface treatments follow separate rules. Metallic coatings, conversion coatings, plastic coatings and linings are not acceptable for preventing SSC. Nitriding to a maximum case depth of 0.15 mm (0.006 in) is acceptable below the lower critical temperature. Controlled shot-peening is acceptable at maximum shot size 2.0 mm (0.080 in) and Almen intensity no greater than 10C.
HIC and SWC Evaluation of Flat-Rolled Products
The equipment user shall consider HIC and SWC when evaluating flat-rolled carbon steel products for sour environments containing even trace amounts of H₂S, and shall consider HIC/SWC testing of those products. This duty applies below the 0.3 kPa threshold that governs SSC selection.
Sulphur level is the dominant variable. Typical maximum acceptable levels are 0.003 % mass fraction for flat-rolled products and 0.01 % mass fraction for seamless products. Conventional forgings below 0.025 % sulphur, and castings, are not normally considered sensitive to HIC or SOHIC.
Seamless pipe sits in a different risk class. HIC and SWC leading to loss of containment has occurred only rarely in seamless pipe and other non-flat-rolled products, and modern seamless pipe is much less sensitive than older product. The standard still sees benefit in evaluating seamless pipe where the consequences of failure justify it.
Rust, sulphur or oxygen in the service environment, particularly alongside chloride, is thought to raise the probability of damage. SOHIC and SZC occurrence is described as rare and not well understood, restricted in all likelihood to carbon steels, with sudden failures recorded in parent steels and in weld HAZs.
Laboratory Qualification Under Annex B
Annex B also covers SOHIC and SZC evaluation (Clause B.4): SSC qualification must precede SOHIC testing, and acceptance requires no ladder-like cracking or cracks exceeding 0.5 mm in the through-thickness direction. For HIC/SWC testing of flat-rolled product under Clause B.5 and Table B.3, evaluation per NACE TM0284 requires Crack Length Ratio CLR ≤ 15 %, Crack Thickness Ratio CTR ≤ 5 %, and Crack Surface Ratio CSR ≤ 2 %.
| Qualification Validity | Test Type | Applied Stress | Test Environment |
| Specific application, or SSC region 1 or 2 | Four-point bend (FPB) | ≥ 90 % AYS | 5 % mass fraction NaCl + 0.4 % mass fraction sodium acetate, pH adjusted with HCl or NaOH |
| Specific application, or SSC region 1 or 2 | Uniaxial tensile (UT) or C-ring (CR) | ≥ 90 % AYS | As above, at H₂S partial pressure appropriate to the intended application or region |
| Specific application, or SSC region 1 or 2 | Double cantilever beam (DCB) | Not applicable | Assessment per NACE TM0177; acceptance criteria by documented agreement |
| All SSC regions of Figure 1 | Four-point bend (FPB) | ≥ 80 % AYS | NACE TM0177 Environment A (5 % NaCl + 0.5 % acetic acid), 100 kPa (15 psi) H₂S, per NACE TM0177 |
| All SSC regions of Figure 1 | Uniaxial tensile (UT) or C-ring (CR) | ≥ 80 % AYS | NACE TM0177 Environment A (5 % NaCl + 0.5 % acetic acid), 100 kPa (15 psi) H₂S, per NACE TM0177 |
Acceptance is binary: no SSC cracks, assessed per NACE TM0316 for four-point bend or NACE TM0177 for the other methods. A minimum of three specimens is tested per test batch. If one specimen fails, the cause shall be investigated. If the source material conforms to the manufacturing specification, two further specimens from the same source may be tested, and the batch is qualified if both pass. Further retests require the purchaser’s agreement.
Cr-Mo tubulars at the 690–760 MPa (100–110 ksi) SMYS grades carry a mandatory testing requirement. SSC resistance must be demonstrated by testing each test batch using the UT test, and the maximum yield for each grade shall be no more than 103 MPa (15 ksi) above the SMYS.
When Carbon Steel Runs Out of Road
Part 2 has an edge. Part 2 addresses cracking only. Steels conforming with A.2 are accepted for SSC in all regions of Figure 1, and Part 2 sets no chloride or upper-temperature limit for them. The move to a CRA is usually driven by general or localized corrosion, which this standard does not address, or by service outside Part 2’s scope. Where a CRA is chosen, Part 3 governs.
The first step is usually austenitic stainless. 316L seamless pipe qualifies under ISO 15156-3 Table A.2 at 22 HRC maximum in the solution-annealed and quenched condition — the same numerical hardness ceiling as carbon steel, but reached through an entirely different metallurgy that also resists general corrosion.
Where chloride and strength requirements both rise, duplex takes over. Duplex 2205 seamless pipe must be solution-annealed and liquid-quenched with 35 % to 65 % ferrite and no ageing heat treatments (ISO 15156-3, Table A.24), and its 450 MPa (65 ksi) minimum yield exceeds most of the API 5L grades Part 2 lists for sour line pipe.
For moderate H₂S with high chloride, super duplex (PREN > 40.0 to 45) allows up to 20 kPa H₂S (ISO 15156-3, Table A.24). Above that, nickel alloys apply.
Super duplex 2507 seamless pipe has a 550 MPa (80 ksi) minimum yield. It qualifies for the 20 kPa band only if the heat’s actual PREN is above 40.0 and not above 45.
For the most aggressive combinations, nickel alloys replace stainless steel entirely. Incoloy 825 seamless pipe handles reducing acid chemistry through its 1.5–3.0 % copper addition in the annealed condition (Type 4a).
Inconel 625 seamless pipe sits above that with 8–10 % molybdenum and 3.15–4.15 % niobium. Where sour service combines high H₂S, high chloride and elevated temperature in one stream, 625 is the common answer — often as a clad or overlay layer on a carbon steel substrate rather than solid wall.
That overlay route connects the two parts directly. Part 2 Clause A.2.1.5 accepts thermally applied overlays provided the substrate heat-treated condition is unchanged or the base metal hardness conforms with A.2.1.2 and A.2.1.4. The composition and cracking resistance of the overlay itself are governed by ISO 15156-3, not Part 2.
At the top of the hierarchy, Hastelloy C-276 seamless pipe runs 15–17 % molybdenum with 3–4.5 % tungsten. Few production environments justify this much alloy, and the ones that do usually involve free sulphur at temperature.
Chemical Composition of Qualified Sour Service Steels
The table gives specification limits from governing product standards (ASTM, API, ISO; not set by ISO 15156-2). Clause A.2.1.2 additionally requires nickel content to be less than 1.0 % mass fraction for general SSC resistance.
| Grade | C, max | Mn | Cr | Mo | Ni | S, max |
| ASTM A106 Gr B | 0.30 | 0.29–1.06 | 0.40 max | 0.15 max | 0.40 max | 0.035 |
| ASTM A333 Gr 6 | 0.30 | 0.29–1.06 | — | — | — | 0.025 |
| API 5L X-52 / L360 | 0.24 | 1.40 max | — | — | — | 0.015 |
| API 5L X-65 / L450 | 0.16 | 1.65 max | — | — | — | 0.010 |
| AISI 4130 (UNS G41300) | 0.28–0.33 | 0.40–0.60 | 0.80–1.10 | 0.15–0.25 | — | 0.040 |
| AISI 4140 (UNS G41400) | 0.38–0.43 | 0.75–1.00 | 0.80–1.10 | 0.15–0.25 | — | 0.040 |
| 316L (CRA step-up) | 0.035 | 2.00 max | 16.0–18.0 | 2.0–3.0 | 10.0–14.0 | 0.030 |
| Duplex 2205 (CRA step-up) | 0.030 | 2.00 max | 22.0–23.0 | 3.0–3.5 | 4.5–6.5 | 0.020 |
| Super Duplex 2507 (CRA) | 0.030 | 1.20 max | 24.0–26.0 | 3.0–5.0 | 6.0–8.0 | 0.020 |
| Incoloy 825 (CRA) | 0.05 | 1.0 max | 19.5–23.5 | 2.5–3.5 | 38.0–46.0 | 0.030 |
| Inconel 625 (CRA) | 0.10 | 0.50 max | 20.0–23.0 | 8.0–10.0 | 58.0 min | 0.015 |
Sulphur is the number to watch on the carbon steel rows. The 0.003 % flat-rolled target sits well below the specification maximums shown. The 0.01 % seamless target equals the X-65 limit.
Mechanical Properties and Hardness Limits
Strength and hardness move together, and in sour service that relationship sets the ceiling. The table pairs minimum mechanical properties with the Part 2 hardness limit applying to each grade or family.
| Grade | Tensile Min, MPa (ksi) | Yield Min, MPa (ksi) | Max Hardness | Region Applicability |
| ASTM A106 Gr B | 415 (60) | 240 (35) | 22 HRC | All regions via A.2 |
| ASTM A333 Gr 6 | 415 (60) | 240 (35) | 22 HRC | All regions via A.2 |
| API 5L X-52 / L360 | 455 (66) | 360 (52) | 22 HRC | All regions via A.2 |
| API 5L X-65 / L450 | 535 (78) | 450 (65) | 22 HRC | All regions via A.2 |
| L80 type 1 casing | 655 (95) | 552 (80) | Per ISO 11960 / API 5CT | All temperatures |
| C90 type 1 casing | 689 (100) | 621 (90) | Per ISO 11960 / API 5CT | All temperatures |
| T95 type 1 casing | 724 (105) | 655 (95) | Per ISO 11960 / API 5CT | All temperatures |
| P110 casing | 862 (125) | 758 (110) | Per API 5CT | ≥ 80 °C (175 °F) |
| Cr-Mo Q&T tubular (Region 2) | Per spec | ≤ 760 (110) actual | 27 HRC | Region 2 via A.3 |
| Cr-Mo Q&T tubular (Region 1) | Per spec | ≤ 896 (130) actual | 30 HRC | Region 1 via A.4 |
| 316L (CRA step-up) | 485 (70) | 170 (25) | 22 HRC | Per ISO 15156-3 Table A.2 |
| Duplex 2205 (CRA step-up) | 620 (90) | 450 (65) | No table limit; ferrite 35–65 % | Per ISO 15156-3 Table A.24 |
| Super Duplex 2507 (CRA) | 800 (116) | 550 (80) | No table limit; ferrite 35–65 % | Per ISO 15156-3 Table A.24 |
| Inconel 625 (CRA) | 827 (120) | 414 (60) | No limit (annealed Type 4a) | Per ISO 15156-3 Table A.13 |
Read the last five rows against the first four. A sour line pipe in X-65 gives 450 MPa (65 ksi) yield at 22 HRC. Duplex 2205 gives the same 450 MPa (65 ksi) minimum yield with corrosion resistance attached (ferrite 35–65 %, no ageing). The CRA route buys design margin as well as corrosion performance.
Dimensional Tolerances for Sour Service Products
ISO 15156-2 sets no dimensional tolerances. They come from the product specification the material is ordered to. The table maps each product form to its governing standard and wall tolerance.
| Product Form | Governing Specification | OD Tolerance | Wall Tolerance |
| Seamless carbon steel pipe | ASTM A106 / A530 | ±1 % (NPS 1½ and under: +1/64 / −1/32 in.) | −12.5 % |
| Low-temperature carbon pipe | ASTM A333 / A530 | Per A530 Table | −12.5 % |
| Line pipe | API 5L / ISO 3183 | ±0.75 % to ±1.0 % by size | −12.5 % (PSL 2) |
| Casing and tubing | API 5CT / ISO 11960 | ±0.75 % to +1.0 % by size | −12.5 % |
| Austenitic SS pipe (CRA) | ASTM A312 / A999 | Per A999 Table 3 | +22.5 % / −12.5 % |
| Duplex / super duplex pipe (CRA) | ASTM A790 / A999 | Per A999 Table 3 | +22.5 % / −12.5 % |
| Nickel alloy pipe (CRA) | ASTM B444 / B829 | ±0.004–0.125 in. by size | +22 % / 0 (nominal wall) |
Minimum-wall ordering carries a sour-service argument. It removes the minus tolerance, so delivered wall never falls below design thickness. Where sour corrosion allowance is already thin, that guarantee is worth more than the price difference against nominal wall.
Marking, Labelling and Documentation
Materials conforming with ISO 15156-2 shall be made traceable before delivery, preferably by marking; suitable labelling or documentation is also acceptable. Tables E.1 and E.2 of the standard give designations that may be used to identify materials.
Materials qualified under Annex B for a special application carry an extra duty. Traceability shall include reference to the environmental conditions of that special application, because the qualification is only valid inside those conditions.
The equipment user may request documentation of the materials used in equipment or components, together with their environmental service limits as defined in the standard. Welding procedure specifications and procedure qualification records shall be available for inspection by the equipment user.
Key Applications of ISO 15156-2 Qualified Materials
Sour Line Pipe and Gathering Systems
API 5L grades A through X-65, and their ISO 3183 equivalents L245 through L450, dominate sour line pipe. The 22 HRC parent metal limit and the 250 HV weld limit are the two numbers that govern the purchase, and seam weld conformance is as mandatory as parent metal conformance.
Downhole Casing and Tubing
Casing and tubing selection runs through Table A.3 and its temperature gates. L80 type 1, C90 type 1 and T95 type 1 serve at all temperatures; N80, P110 and the higher Q&T grades need minimum service temperatures of 65 °C, 80 °C or 107 °C before they qualify.
Pressure Vessels and Separators
Flat-rolled plate for vessels and separators triggers the HIC and SWC duty, because flat-rolled product is where planar inclusions and segregation banding concentrate. ASME Section IX P-No 1 Group 1 and 2 steels are acceptable, with sulphur ordered to the 0.003 % HIC target rather than the specification maximum.
Wellhead and Flange Bolting
Bolting denied atmospheric exposure must conform to A.2.1, which in practice means A193 B7M bolts with A194 2HM or 7M nuts. The lower strength of M-grade bolting can require derating the equipment pressure rating, a consequence worth catching at design stage rather than at assembly.
Clad and Overlay Construction
CRA-clad carbon steel splits the duty between the two parts. The substrate follows Part 2 hardness and heat-treatment rules; the overlay follows Part 3. Nickel alloy pipe in 625 is the usual cladding choice where solid-wall CRA cost cannot be justified across a full flowline length.
Summary
ISO 15156-2 turns sour service into two numbers and a map. Establish H₂S partial pressure and in situ pH, place the result on the Figure 1 region map, then select from the annex that region permits. Keep parent metal at 22 HRC and welds at 250 HV, and the common line pipe, casing and vessel steels qualify without testing.
The limits bite where severity climbs. Region 3 narrows selection to Annex A.2 alone, flat-rolled product carries a separate HIC duty at even trace H₂S, and no coating or lining will substitute for correct base metal selection. Where a CRA is selected instead, qualification follows ISO 15156-3.
Frequently Asked Questions
-
What H₂S Partial Pressure Triggers ISO 15156-2 Selection?0.3 kPa (0.05 psi). At or above that partial pressure in the gas, SSC-resistant steels shall be selected using Annex A.2. Below it, the standard does not address selection in detail and normally no special precautions are required — though highly susceptible steels can still crack, and the HIC duty for flat-rolled products applies at even trace H₂S levels.
-
Why Is the Hardness Limit 22 HRC?It comes from correlations of heat treatment, chemical composition, hardness and field failure experience accumulated across every revision of NACE MR0175. It is an empirical threshold, not a calculated one. The higher limits permitted for chromium-molybdenum steels rest on the same kind of correlation applied to that family.
-
What Are the Four SSC Regions?Region 0 sits below 0.3 kPa (0.05 psi) H₂S. SSC Regions 1, 2 and 3 run from lowest to highest severity on the Figure 1 map of H₂S partial pressure against in situ pH. Region 1 permits selection from A.2, A.3 or A.4; Region 2 from A.2 or A.3; Region 3 from A.2 only.
-
Do As-Welded Carbon Steels Need Post-Weld Heat Treatment?No, provided they conform with the Table A.1 hardness requirements. Tubular products with SMYS not exceeding 360 MPa (52 ksi) listed in Table A.2 are acceptable as-welded, and hardness testing of welding procedures may be waived for them if the equipment user agrees. Weldments outside those requirements need PWHT, at a minimum 621 °C (1,150 °F) for low-alloy steels.
-
Can Coatings or Linings Prevent SSC?No. The standard states that metallic coatings, conversion coatings, plastic coatings and linings are not acceptable for preventing SSC. Thermally applied overlays are acceptable under conditions set in A.2.1.5, and nitriding to a maximum 0.15 mm (0.006 in) case depth below the lower critical temperature is permitted as a surface treatment.
-
What Sulphur Level Does HIC Resistance Require?Typical maximum acceptable levels are 0.003 % mass fraction for flat-rolled products and 0.01 % mass fraction for seamless products. Conventional forgings below 0.025 % sulphur and castings are not normally considered sensitive to HIC or SOHIC. These are HIC targets, not specification maximums, and they are often below what ASTM chemistry allows.
-
When Should I Move From Carbon Steel to a CRA?Typically when corrosion (mass loss) makes carbon steel unsuitable. ISO 15156-2 is concerned only with cracking and does not address general or localized corrosion. Annex A steels are accepted for SSC in all Figure 1 regions, with the casing temperature gates in Table A.3. The decision then moves to ISO 15156-3, which qualifies stainless, duplex and nickel alloys with their own hardness ceilings and environmental envelopes.
-
Is Option 2 Qualification Worth the Cost?It depends on volume. The standard positions Option 2 for bulk materials such as OCTG and line pipe, where the economic incentive to use a steel outside Annex A outweighs the qualification cost. For small quantities of fittings or vessels, the Option 1 selection from Annex A is almost always cheaper.
-
Does ISO 15156-2 Cover Cast Irons?Yes, in A.2.4. Grey cast iron to ASTM A278 Class 35 or 40 and ductile cast iron to ASTM A395 are acceptable as compressor cylinders, liners, pistons and valves. Grey, austenitic and white cast irons shall not be used for pressure-containing parts. They may be used for internal components if the equipment standard permits and the user approves. Ferritic ductile iron to ASTM A395 is acceptable for equipment unless the equipment standard says otherwise. Table A.5 lists irons for packers and subsurface equipment.
-
What Is the Difference Between HIC and SOHIC?HIC is planar cracking driven by hydrogen pressurising trap sites, with no external stress required. SOHIC produces staggered small cracks perpendicular to the principal stress, forming a ladder-like array that links pre-existing HIC cracks, and it does require stress. SOHIC is described as rare and not well understood, with occurrence thought to be restricted to carbon steels.
